Looking for Reliable safety barriers? Original and new brand MTL5581 safety barriers is a good choice for you, please send an inquiry if you need more details about our products.

Product description:

The MTLx581 takes a low-level dc signal from a voltage source in a hazardous area, isolates it, and passes it to a receiving instrument located in the safe area. The module is intended for use with thermocouples utilising external cold-junction compensation. A switch enables or disables the safety drive in the event of thermocouple burnout or cable breakage; a second switch permits the selection of upscale or downscale operation as appropriate.




Number of channels：One

Signal source：Any dc millivolt source

Location of millivolt source:

Zone 0, IIC, T4–T6 hazardous area if suitably certified

Div. 1, Group A, hazardous location

Input and output signal range:

0 to ± 50mV, overrange to ± 55mV

Maximum lead resistance 600Ω

Output resistance:

60Ω nominal

Transfer accuracy@20°C:

Linearity and repeatability < 0.05% of reading or ± 5μV,

whichever is the greater

Temperature drift:

< 2μV/°C, maximum

Response time：

Settles to within 10% of final value within 150μs

Frequency response：

dc to 4kHz nominal

Safety drive on THC burnout:

Two switches enable or disable the safety drive and select

upscale or downscale operation
